SQLite 3.8.x with WAL support

December 3, 2014

Since Plastic (Nov 21th 2014) we support the new 3.8.x SQLite series adding WAL (Write-Ahead-Logging).

In short: it means if you’re using SQLite and Plastic, it will now work much better than before since it now supports several reads simultaneously and less chances for write operations to get blocked waiting for readers to finish and vice-versa. SQLite is a good option to store your repos on your laptop and this improvements means Plastic will work smoother than before. You can be refreshing your Branch Explorer while the SyncView is still recalculating, something that was not possible before this version.

Configuring ignored items on your workspace

November 27, 2014

There are files that you don’t want to submit to version control. Private IDE settings, intermediate build result files, binaries and so on.
This blog post explains you how to handle this in Plastic, manually editing the ignore.conf file. Alternatively you can ignore files using the GUI as explained in the User Guide. Whether you end up using the GUI or editing the file, this blog post will help you understanding how the ignore rules work.

Why do you need to ignore files

This is a familiar scenario that every developer can relate to. You have your workspace nicely set up and linked to its appropriate version control repository. All source files are checked in and organized.
But what happens after you build your project?
Lots of binary files will be created and the version control system will detect them as new!
You might experience the same issue with any other kind of non-permanent file: IDE settings files, temporary files created while you are testing your code, etc.
Obviously, you don’t want these files to be checked in; it could mean you have to review an unnecessarily long list of changes every time you want to check in source code modifications.
Or worse: if you decide to forget about these files and just check them in, your changesets will be cluttered with irrelevant information, making traceability more difficult and allowing errors to slip through.
But don’t worry! This is where the Plastic SCM ignored items come into play.

What is an ignored file

In Plastic SCM, an ignored item is just a private item which will not be added to the pending changes list unless explicitly told so. This is achieved by placing rules inside a file called ‘ignore.conf’, located at the workspace root path. Each private item whose path is matched by one of those rules will be ignored.

How ignored files work

To better understand how this works, let’s have a look at an example.
If you use Microsoft Visual Studio as your IDE, binary files are placed by default at directories called ‘bin’ and ‘obj’.
As we discussed above, you usually wish to prevent those files from being detected as private/new. It’s as simple as adding the following lines to the ‘ignore.conf’ file:
This means that any directory called ‘bin’ or ‘obj’ -along with all of their children, recursively- will be matched and, therefore, excluded from the private objects list.
We can see the result on the next two figures: at first we have almost 100 private files created by the compiler, whereas once we add the rules we see just some IDE settings files (and the ‘ignore.conf’ file, of course!).
These are the pending changes after the build:

And then the pending changes view after the binary directories are configured to be ignored:

Advanced ignore rules

Naturally, the rule format is not limited to directory names. You can also choose to ignore all .suo files by just adding a new rule:
This will remove the three remaining private files in our example (see next image), leaving our pending changes view with our ‘ignore.conf’ file alone. Now we would like it to be ignored too, but we don’t want any other item to be affected. We just want to ignore that specific file, instead of every .conf file or every file called ‘ignore.conf’ (we might have more in our workspace tree that we need to be included at some point). The appropriate rule is:

We can see the results on the next figure: the main ignore.conf has disappeared but some new .conf files haven’t been ignored.

Also, we can decide to remove the AssemblyInfo.cs files from version control. We would just need to delete them on Plastic SCM and then add a line like this in our ‘ignore.conf’ file:
Please note that the rules are case sensitive, so we have to type them accordingly.

Exception rules

But we’re not done yet! Plastic SCM supports exception rules, too. Exception rules are regular rules, preceded by the ‘!’ symbol, that have the opposite effect: they force private items to be always present as new items. To illustrate this, let’s say that there’s a specific binary directory that we want to include if it appears. We only need to specify it as an exception rule:
This will bring back the bin/ results directory of the LibGit2Sharp project.

Wildcard expansion

Both kinds of rules support wildcard expansion. For example: we wish to ignore all files and directories under directories called ‘temp’ but we don’t want .log files directly under them to be ignored. This behavior will be implemented using the following rules:
In the previous example, a “**” string means “any character” whereas the single ‘*’ character means “any character excluding path separators”.


So, this is it! In this post we’ve covered the different possibilities of ignoring private items that Plastic SCM offers, as well as some combinations of them. Feel free to experiment with your own workspace, and don’t hesitate to share your thoughts in our forum!

Orchestrate your development with exclusive checkouts:

November 4, 2014

During the last months, more and more videogame companies have begun to use Plastic SCM. One of the most important requests in this kind of companies is the possibility to perform exclusive checkouts in their controlled files.

When an artist is modifying a texture or a character, he wants to be sure that the file is locked for him and the other artists will not touch the file at the same time. There are also files that can’t be easily merged or even merged at all, like images, animations, simulation data…

In this blog post, I will explain how to configure this scenario with Plastic SCM in both centralized and distributed working environments.

How does it work?

Each time the checkout operation is going to be performed, the client asks the server whether the file needs to be exclusive checked-out or not.

  • If the file was already locked by a different user, it can´t be checked-out.
  • If it´s not locked, Plastic will check in a “lock.conf” if the file matches any of the defined rules. If the file matches the rules, it will be locked.
  • Configure Exclusive checkout in a centralized environment:

    We just need to create a “lock.conf” file and store it in the server folder. As we only have one Plastic centralized server, this server will also be the lock server.

    rep:assets lockserver:localhost:8084

    The "lock.conf" file format is very simple:

  • rep:asssets” is the repository name where we want to configure the exclusive check-outs.
  • lockserver:localhost:8084” is the lock server name (or IP) and port where we want to configure the exclusive check-outs.
  • “*.obj” is a file format rule of the elements we want to lock. Both complete paths and patterns are supported. We specify a rule in each line. Each time we checkout on a path that meets any of the filtered rules, this path will be in exclusive checkout so that no one else can perform a checkout on it at the same time.
  • Configure Exclusive checkout in a distributed environment:

    In a distributed scenario, we have different Plastic servers spread in different locations.

    In that case, to configure an exclusive checkout mechanism , we have to select one server to be the lock server. The “lock.conf” needs be stored in all the Plastic servers, but there will be only one lock server. Let´s make it clearer with an example:


    UserA -> ServerA, with a "lock.conf" file having lockserver configured to itselt. (localhost:8084)

    rep:assets lockserver:localhost:8084

    UserB ->ServerB, with a "lock.conf" file having lockserver configured to the ServerA

    rep:assets lockserver:ServerA:8084

    This way, the ServerA will work as the central node that will manage the locks. Server B will ask ServerA if the file X is exclusively checked-out or not.

    Requiring a head changeset:

    In order to ensure that the exclusive checkout has the head changeset as its base changeset on the working branch, we need to add a keyword (requiehead) to each rule in the "lock.conf" file.

    rep: assets lockserver:localhost:8084
    requirehead *.obj

    During the check-out, on the client side, if the rule says "requiredhead", then it´s checked if the head of the branch is the working changeset.

    If it isn´t, the exclusive checkout is cancelled and the user gets a message to update the workspace to the last changeset of the branch.

    Command line operations:

    There are also two some interesting commands that may help you to improve your workflow in exclusive checkout scenarios:

    cm listlocks server:port

    This command shows the locked items on a server. You can filter the locked items using the next options:

  • --onlycurrentuser: Filters the results showing only the locks performed by the current user.
  • --onlycurrentworkspace: Filters the results showing only the locks performed on the current workspace (matching them by name).
  • Eg:

    cm listlocks localhost:8084

    cm unlock server:port guid

    This command allows to undo item locks on a lockserver.

    It´s important to note that only the administrator of the server will be able to run the'cm unlock' command.

    To specify a GUID, the format should be the 32-digit separated by hyphens format (optionally enclosed in braces):

    or 00000000-0000-0000-0000-000000000000


    cm unlock localhost:8084 2340b4fa-47aa-4d0e-bb00-0311af847865 bcb98a61-2f62-4309-9a26-e21a2685e075

    cm fileinfo item_path --format=str_format

    The fileinfo command provide detailed information about items in the workspace and it´s possible to check if an item is locked or not.


    cm fileinfo character1.png –format={IsLocked}

    Plastic SCM email notifications!

    October 28, 2014

    People love notifications! So let’s add some to Plastic SCM.

    This is a DIY project; it’s not something you’ll find built-in with Plastic SCM. I came with this fast solution to get email notifications when certain Plastic SCM operations were triggered. If you want to have built-in notifications in Plastic, you know you can use the uservoice page to vote up for it.
    Now, you can download the tool from here.


    The entry point for third party tools is the trigger system. Using triggers you can hook up important operations and customize their behavior.

    I’ll take the following ones to start coding a simple notification center:

    • After-checkin
    • After-mkreview
    • After-editreview
    • After-mklabel

    With the four triggers above, I will be able to get an email when a checkin is created, a new code review is created or edited and finally when a new label is created.

    The Plastic SCM triggers provide extra information both before the operation is run (before triggers) and after it finished (after triggers). You can review all the details here. Consuming the standard input or reading the trigger environment variables will help you create smarter and customizable notifications, such us getting notified only when the “README.txt” file has been changed at the release branch by a certain user.

    This is a high level diagram explaining how the tool works:

    The tool

    In order to attach the tool to a Plastic SCM trigger you will need to use the “cm mktrigger” command as follows:

    cm mktrigger after-mklabel "mklabelnotifier" "C:\triggers\plasticnotifier.exe aftermklabel C:\triggers\mklabel.txt"

    You need to specify the trigger type, a name to easily recognize the new trigger and the tool you want to run when the operation is triggered.

    The “plasticnotifier.exe” tool only needs two parameters, the first one is the trigger type and then the configurator file for that trigger type.

    Configuration files

    The source code will understand three different file formats that will serve as an example that you can use to create additional ones.

    Mail list

    The most basic configuration file is the list of email recipients the trigger will use when fired. It looks like as follows:
    This format is valid for the “aftermklabel” trigger. The “AftermklabelTrigger” class will read the entire list and will start sending emails.

    Translation file

    For some triggers you will need to provide a mechanism to translate the Plastic SCM user and get the email. This file will be used by the “AfteReviewTrigger” class to translate the code review assignee user and obtain the email to send the message.

    This is the config file aspect:
    Each line has two fields separated by a semicolon; the first one is the Plastic SCM user ID and the
    second one the user email. The trigger will create an environment variable with the code review assignee user ID. The “plastic notifier” will use this file to obtain the email to send notifications to.

    Complex file

    The last file format has several fields and subfields, take the following content as an example:

    Changeset {0} created with the "{1}" comment.\r\n
    Changeset content:\r\n{2}
    This file format is used by the “AfterCheckinTrigger” class and has two parts: the message and the subscribers.

    The message is the email body that you can customize.

    Three extra fields are available for the message: “{0}”, “{1}” and “{2}” will be automatically replaced by the changeset specification, the changeset comment and the files changed. Again this information is provided by the trigger using environment variables and the standard output.

    The subscribers part is similar to the “Mailing list” format we explained above, but this one has extra information. After the user mail you can write, separated by semicolons, the branches you are interested on for notifications. Using a star (*) you will get notification for all the checkin operations done in the server. In the example above, the user “developer1” will only get notifications for the /main and /main/experimental branches, but the user “admin1” will get an email for every single checkin done in the server.

    Further work

    With the tool provided, you can get notifications when:
    • A new label is created.
    • A new code review has been assigned to you.
    • A new checkin in a certain branch has been performed.
    But this is just a small preview of what you can get if you continue working. Here come some suggestions:
    • Get an email when permissions are changed.
    • Get an email when somebody tries to remove a repository.
    • Get an email when certain files are changed.
    The source code is written in C# but you can grab it and translate it to any other language. You can improve the code and complete it, and, if you do, please don’t forget to share it!

    Happy notifying!

    How the 2d version tree works

    October 27, 2014

    This article explains how the 2d version tree works and what it exactly renders.

    We realized 2d-version-tree is one of the less understood features in Plastic, so a detailed explanation is definitely worth.

    Item-level trees vs changeset trees

    Plastic displays the evolution of a repository rendering the Branch Explorer. It is an overall view of what happened at a global level instead of going file per file.

    While this is very useful in almost all cases, there are users who miss the old days of individual version trees. Maybe they have a pre-Plastic 4.0 background, maybe they come from good-ol ClearCase or maybe they just find it more natural.

    Plastic SCM works on a changeset basis: changesets are the core of the system and not individual file histories. The reason is merge tracking: merges are tracked at the changeset level and not the individual file revision level.

    We actually change this when we moved to version 4 a few years ago. Before that merges were tracked at the individual item (directory/revision) level.

    What does it mean? Well, when you had to merge, let’s say 1200 files (or directories) Plastic 3.0 had to walk 1200 different history trees finding merge links and ancestors. In 4.0 and beyond it only walks one single tree. There’s no way for 3.0 to outperform 4.x (and later) in merge speed because the old version simply had to do tons of work. I won’t cover all the details, but this radical change didn’t only benefit merge performance but also the overall system speed and distributed features.

    A simple 2d tree scenario

    Let’s go through a very simple branch/merge scenario and let’s follow the history of a single file inside our repository. The following figure shows the Branch Explorer of our repo and where the file “foo.c” was modified.

    As you can see the file was added in changeset 1, later branched and changed on changeset 5, and this change was merged back to “main” in changeset 7.

    How does the version tree of the “foo.c” file looks like?

    Look at the following figure: you probably expect something like the graphic on the right, but this is not how Plastic works. Plastic actually created only 2 revisions of “foo.c” so far: one created on changeset 1 and the second one created on changeset 5.

    You may wonder what happened during the merge: well, changeset 7 simply includes the revision loaded by changeset 5 because there is no merge conflict and hence no need to create an extra revision for the file. This is what we call a “revision replacement” because changeset 7, which is a children of 4, simply replaces the loaded revision of “foo.c” as the result of the merge.

    You probably expected something like the graphic on the right of the figure above and if fact this is how things worked on Plastic 3 and before, but the underlying merge tracking mechanism changed in 4.0 and beyond. There’s no need to create extra revisions of the file for trivial merges which greatly reduces the amount of operations to be performed.

    Think about it: suppose you added 10k files on a branch and later merged them back to main: 3.0 was actually creating another 10k revisions of the files on main, while 4.x and beyond simply say “hey, load them on the main branch, that’s all” saving precious time.

    So, how does the 2d-version-tree renders the previous case? Check the following figure:

    As you can see the 2d-version-tree decorates the “real” version tree of the file with information from the Branch Explorer (changeset history) so you can better understand what is going on with the file.

    The changesets marked as “U” mean the file was unchanged on this changeset, but it is still rendered so we can understand how the file evolved through the repo history. Looking at this diagram you can understand that the revision changed on branch1 was the one finally labelled as BL001. Looking at the “raw” tree (or the history of the file) you wouldn’t have enough info to understand it.

    A slightly more complex 2d-tree scenario

    Look now at the following Branch Explorer:

    It is slightly more complex than the previous since it involves 3 branches and a couple of merges. Our file “foo.c” was simply added on changeset “1” and changed on “9”. Look how the “real” version tree looks like:

    Looking at this tree you’d never understand what actually happened to the branch! How did it end up in branch2? Was it ever merged? You can’t tell.

    Now, let’s look at the 2d-version-tree:

    Still it explains there are only two revisions of the file, but by rendering the “unchanged changesets” where it was rendered you can now understand how the file evolved and how it end up being labelled in BL001.

    A 2d-tree with a file concurrently changed

    The cases so far didn’t run into merge conflicts: foo.c wasn’t modified in parallel and involved in a real merge.

    The following Branch Explorer renders a third scenario where foo.c is finally modified in parallel and merged:

    Now foo.c is added in 1 as before but changed both on 4 and 9.

    This is how the raw version tree looks like:

    Whenever we have a *real* merge we’ll be able to render a merge link between two revisions, which greatly helps understanding the scenario, but still, the graphic above falls short to explain what actually happens to the file, doesn’t it?

    You didn’t do a merge from “branch2” to “main” so, why do you have such a merge link?

    That’s why the 2d-version-tree solves the scenario as follows:


    I hope that reading through the previous cases helps understanding how the 2d-version-tree works and getting a better idea of why it explain the history the way it does.

    Don’t hesitate to reach us if you have any questions.

    Directory Notifications to find changes

    October 22, 2014

    Pending Changes is now faster than ever because it doesn’t need to traverse the workspace anymore. We have implemented a new mechanism based on Windows Directory Notifications to detect workspace changes faster than ever.

    It is available only on Windows but we’ll eventually implement it for Linux and Mac (based on their corresponding notification mechanisms).

    What does it mean for you? Well, as soon as you install or (or higher) Pending Changes will be faster. You’ll clearly notice the speed up with really large workspaces (in number of files) and with slow disks. The slower the disk is, the clearer the speed up will be.

    How Pending Changes works? (without directory notifications)

    Whenever you click on “refresh” on Pending Changes Plastic triggers a search to find the files that have been modified on your workspace.

    The diagram below describes the process in detail:

    • The process checks the “pending changes options” first: if only checkouts are requested, then there’s nothing to look for, just print the list. That’s why working with checkouts makes sense for huge workspaces (>400k files).
    • If the options to find changed files on disk are set, the directory walk will start.
    • For each directory starting on the root of the workspace Plastic will try to find changed files. It will compare the timestamp on disk with the stored timestamp on the wktree file: the plastic.wktree file (inside .plastic) stores the metadata of the file. It know “how it was” after the last update or checkin. So if the timestamp and size doesn’t match, the file was changed. If timestamp doesn’t match and size does, Plastic hashes the file. It is slower but it makes sure the file is different. Alternatively there’s an option to force Plastic to always find changes based on file contents (ignoring the timestamp) which is definitely slower but required on some scenarios.
    • At the end of the disk walk, Plastic has a list of all the modified files on your workspace.

    The diagram doesn’t show the last step (if the option is set): find “moved and renamed files” by matching potential added and deleted files.

    What I want to explain with the diagram is that there is at least one IO operation by directory. If you keep pressing “refresh” on the Pending Changes view, chances are the list will be filled quickly: after the first traversal the workspace will be loaded in the file system cache so the next reads will be blazing fast. But if your disk is not very fast, or your computer is performing a lot of IO, or using a lot of RAM, chances are that your workspace won’t be entirely loaded in the file system cache, and then walking it will take longer.

    You probably noticed it when after some coding you go back to Plastic, click refresh, and it takes longer than usual. This is exactly what we wanted to improve with this feature.

    How Pending Changes with Directory Notifications works?

    It is rather simple: we use Windows directory notifications to listen to events on the workspace directory. Each time a file is written, deleted, added, moved or renamed inside the workspace, Plastic gets a notification.

    So, while we perform an initial directory traversal the first time the Pending Changes view loads, no other full directory walk will be needed later, greatly speeding up the operation.

    What we do is the following: after the first traversal we keep a tree with the metadata of what is on disk, and we invalidate parts of it (on a directory basis) each time a change happens inside it. This way Pending Changes only has to reload parts of the tree instead of walking the workspace entirely. It saves precious time while still being a robust solution.

    One of the issues with Directory Notifications on Windows is that it can’t really notify file or directory moves, so you have to match pairs of added/deleted. Instead of trying to pair the notifications we just invalidate parts of the tree and let the regular Pending Changes code to do the rest.

    So, there’s still room for improvement but our initial tests probed that the extra complexity of doing a more precise event tracking didn’t pay off compared to just invalidating parts of the tree.


    Chances are you are already using it :-)

    If you’re using or higher or or higher, you’re already enjoying the Directory Notifications powered Pending Changes view.

    Branch differences

    September 22, 2014

    We’ve implemented a batch of improvements in the branch/cset/label diff window in the last months. Some of the improvements are pretty recent and some others have been around for months already. I’ll be walking through them and explaining how they help when running diffs on a daily basis.

    Improved diff groups

    Availability: (Sep 12th 2014) and (Sep 19th 2014).

    The first feature is the ability to group together files and directories that only differ in file system permissions (typical scenario when some files get executable flag on Linux). Now the files that only differ in file system permissions are grouped together so you can better focus on what was actually modified.

    The goal here is to let you focus on the real changes when diffing code for a review or when figuring out why a bug occurred, by grouping away potentially uninteresting changes.

    The second feature is a slight modification since we released Item Merge Tracking last year. Now the files that were in changed/changed merge conflicts will show up in their own category:

    And this is how the same info was grouped before:

    As you can see now he highlight the “changed/changed” and put them at the very beginning of the list so you can focus first on the diffs of files which were modified by both contributors during a merge, and hence are potentially worth reviewing.

    Analyze diffs

    Availability: (March 3rd 2014) and (March 10th 2014).

    There’s a story behind this feature: sometimes you find yourself reviewing a task where the developer modified a huge number of files, like 200 or so.

    You launch the diff and then you see the counter with a big number on it: 100, 200, 250 files… whatever. Your feeling will be: “oh god! Let’s go and grab some coffee first”. Which, in short, means that huge reviews are extremely unproductive because you enter in this state of mood of “this will take a loooooong time”.

    And sometimes that’s correct and you truly have to spend a long time.

    But chances are that many of the files changed by your colleague only contain trivial changes. Like a rename on a method that affects a bunch of files, but all this files only have a trivial modification.

    How can you figure out beforehand? Well, that’s why we’ve introduced “analyze changes”.

    You click on the new “analyze differences” button and then Plastic will use cloc to calculate the lines of code being modified. You can see it running in my review with 284 files below:

    And here goes the result once the changes were classified:

    As you can see there’s a new SLOC column where you see a summary of the lines of code being added, changed and deleted (since it uses SLOC and not LOC, there will be cases where changes only affected comments or white lines and hence they’ll show up as zero changes!).

    You can sort the column and then check how many files have really “big changes” and it will have a positive effect on your mood and willingness to go through the entire list, which at the end of the day means increased productivity :-)

    In my screenshot you can see how the selected file just contains a namespace change… which is not a big deal to review and in fact in my example this refactor affected more than 180 files out of 280, not bad.

    This is the first step towards true “semantic multi-file diff” :-)

    Find in files

    Available since: (Jun 6th 2014) and (July 1st 2014).

    Sometimes you’re diffing a branch and then you would like to find something (a method call, a given text or comment) inside the files being diffed.

    That’s why we added “find in files” to the diff window: click on the new “find in files” button or “CTRL+SHIFT+F” and the following panel will show up:

    You can enter the pattern to find, then decide whether you want to search in both sides or only one of them, select the extension or whether you want to select the search to the filtered files in the diff window.

    And the results are displayed as follows:

    With the occurrences of the left and right sides separated to ease the navigation.

    In my case I was looking for the word “comment” and it is clearly more common before the change, which means the word was deleted from the file.

    Our plan is to implement another feature on top: “search only in diffs” to restrict the search to the text blocks which were really modified. This is useful, for instance, to see if a certain method call has been really used in the new code or not.

    Annotate each contributor

    Available since: (Jun 18th 2014) and (Jun 26th 2014).

    We added the option to launch the annotate from within the diff view so you can instantly see the detailed information about each line of each of the two sides of a diff.

    I find it especially useful when going through complex merges: look at the screenshot above. Do you see the “Yes” at the end of the annotate? It means this line was modified during a merge. Which means the two contributors to the merge don’t contain the line but it was actually edited during the merge (at least prior to the checkin). This information is very useful to figure out what was really changed manually and what simply comes directly from one of the merge contributors.

    As it happens with some of the other features explained in this blog post, this is just a first step. We’re working on more improvements to item merge tracking to be able to display on files in the “changed-changed” group exactly which lines come from merges or were modified on the branch.

    Info about binary files

    Available since: (Aug 6th 2014) and (Aug 8th 2014).

    Sometimes you’re diffing a branch and there are binary files that can’t be diffed. So far we were just displaying a message telling “diff not available” (although you can CTRL+D to launch the external diff, for images for instance). Now we display useful metadata to understand the change:

    The date and size and author are especially useful to understand what is going on with the file.

    For images our plan is to embed the Image Diff here (check the gallery to find out more about the tool).

    Real Time Web Analytics
